| Operating Voltage | DC 9~90V |
| Operating Current | Approx. 45mA@12V (Standby Current 8mA) |
| Dimensions | 84mm*38mm*12mm |
| Positioning Method | GPS/BeiDou |
| Positioning Error | <10m (Reference data, positioning error is related to terrain, time, and other factors) |
| Communication Network | 4G Network |
| Communication Method | TCP/UDP |
| Operating Temperature Range | -25℃ ~ +75℃ |
| Storage Temperature Range | -40℃ ~ +85℃ |
| Terminal Net Weight | 40g |
| Backup Battery | 55mAh |
| No. | Item | Specifications | Remarks |
|---|---|---|---|
| 1 | Operating Voltage | DC 9~90V | - |
| 2 | Operating Current | 45mA@12V (Standby 8mA) | - |
| 3 | Dimensions | 84×38×12mm | - |
| 4 | Positioning | GPS/BeiDou | - |
| 5 | Positioning Error | <10m | Lab test data |
| 6 | Network | 4G | - |
| 7 | Protocol | TCP/UDP | - |
| 8 | Operating Temp | -25℃~+75℃ | - |
| 9 | Storage Temp | -40℃~+85℃ | - |
| 10 | Weight | 40g | - |
| 11 | Battery | 55mAh | - |
| Feature Category | Function | Description |
|---|---|---|
| Remote Monitoring | Real-time Tracking | Instant vehicle status query |
| Scheduled Tracking | Custom monitoring intervals | |
| Blind Zone Storage | 600 data points capacity | |
| Status Query | Remote diagnostics | |
| Mileage Setup | Initial value configuration | |
| Firmware Upgrade | Manufacturer support required | |
| Alarm System | Geo-fence | 10 zone limits |
| Overspeed Alert | Custom speed threshold | |
| Low Voltage | <10V trigger | |
| Power Loss | SMS notification | |
| Unauthorized Move | ACC-off detection | |
| Vibration Alert | Impact detection | |
| Extended Features | Turnpoint Upload | Direction change detection |
| Cell Tower Locating | Network-based positioning | |
| Power Saving Mode | 3D motion detection | |
| SMS Query | Send "CC" for location |
Verify device integrity and accessory completeness
Power off before inserting SIM card
Red wire: Constant +12V
Black wire: Chassis ground
